Our Erbium-Doped Glass Laser, known as the 1535nm Eye-Safe Er Glass Laser, excels in eye-safe rangefinders. It offers reliable, cost-effective performance, emitting light absorbed by the cornea and crystalline eye structures, ensuring retina safety.In laser ranging and LIDAR, especially in outdoor settings requiring long-distance light transmission, this DPSS laser is essential. Unlike past products, it eliminates eye damage and blinding hazards. Our laser uses co-doped Er:Yb phosphate glass and a semiconductor laser pump source to produce a 1.5um wavelength, making it perfect for Lidar, Ranging, and Communications.
An Er:Glass laser is a solid-state laser that uses erbium-doped glass as its active medium, emitting light typically at a wavelength of 1.54 micrometers.
Click to the FAQ about Erbium Doped Glass Laser
KEY FEATURESHuman eye safety Compact and lightweight High photonic conversion efficiency Adaptability to harsh environments | APPLICATIONSLaser ranging Laser LIDAR Laser communication |
Technical Data
LM-1535-PXXX-C3 | ||||
Parameters | Typical Value | Unit | ||
Optics | Wavelength | 1535 | nm | |
Pulsed Width(FWHM) | ≤12 | ns | ||
Pulsed Energy | 100 | 200 | uJ | |
Peak Power | 25 | 50 | kw | |
Energy Stability | ≤5 | % | ||
Beam divergence angle | ≤0.5 | mrad | ||
Electric | Operating voltage | 2 | V | |
Operating current | 6 | 12 | A | |
Operating frequency | 1-10 | Hz | ||
Pulse width | 1.0-2.5 | ms | ||
Environment | Operating Temp. | -40-75 | ℃ | |
Storaging Temp. | -50-75 | ℃ | ||
Lifespan | 10,000,000 | times | ||
Weight | <15 | g | ||
